Opis
Svetlobni vir: LED, Difuzor: Opalni, Kot snopa: 120°, Frekvenca: 50/60 Hz, Ohišje: PC, Difuzor: PC, Kabel: H05V-U 1x0,5 mm², Prehodna napeljava: 5 x 1,5 mm², Sponke iz nerjavečega jekla z vijaki, dve sponki na obeh straneh difuzorja, Montaža: Nosilci iz nerjavečega jekla (2 kosa), Krmilna naprava je priložena
Besedilo je strojno prevedeno.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: 05400727
EAN koda: 4016705407279
Registrirana blagovna znamka: Protec
Ime proizvajalca: Würth Elektrogroßhandel GmbH & Co. KG
Naslov proizvajalca: Reinhold Würth Straße 12 – 16
Poštna številka proizvajalca: 74653
Kraj proizvajalca: Künzelsau
Država proizvajalca: Germany
Telefon proizvajalca: +496196477412
Elektronski kontakt proizvajalca: https://www.protecclass.de/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki
| Vrsta izdelka |
LED svetilka za vlažne prostore s pokrovom |
|---|---|
| Barva |
siva |
| Razred energetske učinkovitosti |
D (A - G) |
| Protection class according to IEC 61140 |
I |
| Width |
103 mm |
| Conductor cross section |
1.5 mm² |
| Housing colour |
Grey |
| Voltage type |
AC |
| With movement sensor |
FALSE |
| Type of grid |
None |
| Type of control gear |
Not required |
| Colour rendering index CRI |
80-89 |
| Suitable for wall mounting |
TRUE |
| With light sensor |
FALSE |
| Suitable for suspended mounting |
FALSE |
| Number of poles |
5 |
| Length |
1506 mm |
| Height/depth |
84 mm |
| Housing material |
Plastic |
| Lamp type |
LED not exchangeable |
| Suitable for light line configuration |
FALSE |
| Suitable for emergency lighting |
FALSE |
| Light outlet |
Direct |
| Light distribution |
Symmetric |
| Material cover |
Plastic, structured |
| Impact strength |
IK08 |
| Nominal voltage |
220-240 V |
| Emergency power supply integrated |
FALSE |
| Degree of protection (IP) |
IP66 |
| With light source |
TRUE |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 |
FALSE |
| Covering of the luminaire with thermally insulating material possible |
FALSE |
| Suitable for number of light sources |
1 |
| Suitable for built-in mounting |
FALSE |
| With control gear |
TRUE |
| Suitable for workplace according to EN 12464-1 |
FALSE |
| Suitable for surface mounting |
TRUE |
| Beam angle |
> 80° - Extreme wide beam |
| Colour temperature |
4000-4000 K |
| Max. system power |
55 W |
| Rated luminous flux according to IEC 62722-2-1 |
8000 lm |
| Colour of light |
White |
| IFTTT support available |
FALSE |
| Type of wiring |
Loop-through wiring included |
| Rated lifetime L70/B50 at 25 °C |
50000 h |
| Rated ambient temperature according to IEC 62722-2-1 |
-20-40 °C |
| Filament test according to IEC 60695-2-11 |
None |
| Dimming 0-10 V |
FALSE |
| Dimming 1-10 V |
FALSE |
| Dimming DALI |
FALSE |
| Dimming DMX |
FALSE |
| Dimming potentiometer (integrated) |
FALSE |
| Dimming LineSwitch |
FALSE |
| Dimming manufacturer's proprietary system |
FALSE |
| Dimming mains voltage modulation |
FALSE |
| Dimming phase cut-off (trailing edge) |
FALSE |
| Dimming phase cut-on (leading edge) |
FALSE |
| Dimming programmable |
FALSE |
| Dimming RF |
FALSE |
| Dimming Sine Wave Reduction |
FALSE |
| Dimming Touch and Dim |
FALSE |
| Dimming Zigbee |
FALSE |
| Dimming with push-button |
FALSE |
| No dim function |
TRUE |
| Dimming DSI |
FALSE |
| Operation by Bluetooth |
FALSE |
| Compatible with Apple HomeKit |
FALSE |
| Compatible with Google Assistant |
FALSE |
| Compatible with Amazon Alexa |
FALSE |
| Dimming DALI-2 |
FALSE |
| Colour of light adjustable |
No |
| Luminous flux adjustable |
Positions |
| Beam angle adjustable |
No |
| Exchangeable control gear |
TRUE |
| Compatible with Casambi |
FALSE |
| Energy efficiency class of the light source according to EU regulation 2019/2015 |
D |
| Suitable for ceiling mounting |
TRUE |
| Surface protection housing |
Untreated |
