Opis
Spojni rele za DIN letev z vijačnimi spoji, 2 preklopna kontakta 8 A / 250 V AC, napetost tuljave 110 V DC, kontaktni material AgNi, z integrirano LED in zaščito pred EMC motnjami
Besedilo je strojno prevedeno.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: 4C.02.9.110.0050
EAN koda: 8012823320571
Registrirana blagovna znamka: Finder
Ime proizvajalca: FINDER GmbH
Naslov proizvajalca: Hans-Böckler-Str. 44
Poštna številka proizvajalca: 65468
Kraj proizvajalca: Trebur
Država proizvajalca: Germany
Telefon proizvajalca: +490614720330
Elektronski kontakt proizvajalca: https://www.findernet.com/de
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki
| Vrsta embalaže |
Piece |
|---|---|
| Vrsta izdelka |
povezovalni rele |
| Vrsta |
4C.02.9.110.0050 |
| Priključek |
vijačna sponka |
| Delovna napetost (maks.) |
110 V/DC |
| Kontakt |
2 menjalo |
| Material kontakta |
AgNi |
| Nazivna napetost |
110 V/DC |
| Preklopna napetost (maks.) |
250 V/AC |
| Preklopni tok maks. |
8 A |
| Značilnosti |
z LED |
| Vrsta zaščite |
IP20 |
| Globina |
68.1 mm |
| Širina |
15.8 mm |
| Višina |
82.9 mm |
| Mere |
(Š x V x G) 15.8 x 82.9 x 68.1 mm |
| Vsebina |
1 kos |
| Skladnost z RoHS |
Ja |
| Nominal current |
8 A |
| Width |
15.8 |
| Height |
66 mm |
| Depth |
82.85 mm |
| Max. starting current |
15 A |
| With detachable clamps |
FALSE |
| Drive, polarization |
Polarity free |
| Drive, switching attitude |
Mono stable |
| With forced-guided contacts |
FALSE |
| Type of switch contact |
Single contact |
| Complete with socket |
TRUE |
| Type of electric connection |
Screw connection |
| Rated control supply voltage DC |
110-110 V |
| Voltage type (operating voltage) |
DC |
| Degree of protection (IP) |
IP20 |
| With LED indication |
TRUE |
| Operating voltage DC |
80.3-121 V |
| Voltage type for actuating |
DC |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Number of contacts as change-over contact |
2 |
