Opis
Spojni rele za DIN letev z nateznimi vzmetnimi sponkami, 1 preklopni kontakt 6 A / 250 V AC, napetost tuljave 230-240 V AC, kontaktni material AgNi trdo pozlačen, LED in zatiranje EMC motenj sta integrirana v vtičnico
Besedilo je strojno prevedeno.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: 386182405060-10
EAN koda: 2050010678391
Registrirana blagovna znamka: Finder
Ime proizvajalca: FINDER GmbH
Naslov proizvajalca: Hans-Böckler-Str. 44
Poštna številka proizvajalca: 65468
Kraj proizvajalca: Trebur
Država proizvajalca: Germany
Telefon proizvajalca: +490614720330
Elektronski kontakt proizvajalca: https://www.findernet.com/de
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki
| Vrsta embalaže |
Single |
|---|---|
| Vrsta izdelka |
povezovalni rele |
| Vrsta |
38.61.8.240.5060 |
| Odzivna napetost (min.) |
230 V/AC |
| Delovna napetost (maks.) |
240 V/AC |
| Kontakt |
1 menjalo |
| Material kontakta |
zlato |
| Nazivna napetost |
230 V/AC |
| Preklopna napetost (maks.) |
250 V/AC |
| Preklopni tok maks. |
6 A |
| Značilnosti |
z emv preprečevanjem radijskih motenj vezja |
| Vrsta zaščite |
IP20 |
| Globina |
76 mm |
| Širina |
6.2 mm |
| Višina |
93.6 mm |
| Mere |
(Š x V x G) 6.2 x 93.6 x 76 mm |
| Vsebina |
1 kos |
| Skladnost z RoHS |
Ja |
| Način nadzora |
monostabilno, 1 tuljava |
| Nominal current |
6 A |
| Width |
6.2 mm |
| Height |
93.6 mm |
| Depth |
76 mm |
| With detachable clamps |
FALSE |
| Drive, polarization |
Polarity free |
| Drive, switching attitude |
Mono stable |
| With forced-guided contacts |
FALSE |
| Type of switch contact |
Single contact |
| Complete with socket |
TRUE |
| Type of electric connection |
Spring clamp connection |
| Rated control supply voltage AC 50 Hz |
230-230 V |
| Rated control supply voltage AC 60 Hz |
230-230 V |
| Material of contact surface |
Gold |
| Degree of protection (IP) |
IP20 |
| With LED indication |
TRUE |
| Material contact |
Other |
| Voltage type for actuating |
AC |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
0 |
| Number of contacts as change-over contact |
1 |
| Material of contact insert |
Thermoplastic |
