Varnost izdelkov (GPSR)
Proizvajalčeva koda: 7LF6310
EAN koda: 4001869568010
Registrirana blagovna znamka: Siemens
Ime proizvajalca: Siemens AG
Naslov proizvajalca: Siemenspromenade 2
Poštna številka proizvajalca: 91058
Kraj proizvajalca: Erlangen
Država proizvajalca: Germany
Telefon proizvajalca: +498938035491
Elektronski kontakt proizvajalca: https://www.siemens.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki
| Vrsta izdelka |
časovno stikalo za luč na stopnišču |
|---|---|
| Način montaže |
montažna letev (DIN letev) |
| Mere |
(Š x V x G) 97.0000 x 56.0000 x 83.0000 mm |
| Širina |
97.0000 mm |
| Višina |
56.0000 mm |
| Globina |
83.0000 mm |
| Mounting method |
DIN rail |
| Function |
Electronic |
| Built-in depth |
64 mm |
| Width in number of modular spacings |
1 |
| Type of control voltage 1 |
AC |
| Type of control voltage 2 |
AC/DC |
| Wiring system |
3 and 4 wire configuration |
| Pre-warning of switching-off |
None |
| Repetitive |
Repetitive |
| Voltage type (supply voltage) |
AC |
| Max. incandescent lamp load |
2000 W |
| Max. load fluorescent lamp |
1000 VA |
| Max. load fluorescent lamp (Duo circuit) |
1000 VA |
| Max. load fluorescent lamp (parallel compensated) |
1000 VA |
| Rated switch current |
16 A |
| Push button glow-lamp current |
50 mA |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
1 |
| Number of contacts as change-over contact |
0 |
| Max. switching power LED |
1000 |
| UKCA |
ni pomembno |
