Opis
Vtičnica 3-smerna Wago-vtična / vpenjalna tehnologija brez halogena C-profilna prometna rdeča Vtičnica s povečano zaščito pred naključnim stikom, predhodno ožičena, je mogoče priključiti s 3-polnim sistemom priključkov s hitrim pritrditvijo za sistem namestitve naprave s C-profilom. Kabelski priključek prek vtičnih sponk 1,5 - 2,5 mm2 ali prek povratnega polariteta zaščitnega priključnega sistema.
Besedilo je strojno prevedeno.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: GS30003020
EAN koda: 4012740851381
Registrirana blagovna znamka: Hager
Ime proizvajalca: Hager Vertriebsgesellschaft mbH & Co. KG
Naslov proizvajalca: Zum Gunterstal
Poštna številka proizvajalca: 66440
Kraj proizvajalca: Blieskastel
Država proizvajalca: Germany
Telefon proizvajalca: +4968429450
Elektronski kontakt proizvajalca: https://hager-sicurezza.it/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnični podatki
| Vrsta izdelka |
stenski nadometni kanal |
|---|---|
| Komponente |
vključni modul |
| Izvedba |
3-smerna vtičnica |
| Vsebina |
1 kos |
| Barva |
prometno rdeča |
| Mere |
(Š x V x G) 180 x 50 x 61 mm |
| Širina |
180 mm |
| Višina |
50 mm |
| Globina |
61 mm |
| Nominal current |
16 A |
| Nominal voltage |
250 V |
| Mounting method |
Wall duct |
| Colour |
Red |
| Halogen free |
TRUE |
| Number of units |
3 |
| Lockable |
FALSE |
| With hinged lid |
FALSE |
| Connection type |
Push-in clamp |
| Surface protection |
Untreated |
| With signal lamp |
FALSE |
| Number of phases |
1 |
| With enhanced contact protection |
TRUE |
| Frequency |
50-60 MHz |
| With on/off switch |
FALSE |
| Label space/information surface |
TRUE |
| Material quality |
Thermoplastic |
| Rotated central insert |
FALSE |
| Overvoltage protection |
FALSE |
| Fault current protection |
FALSE |
| Special power supply |
Additional safety power supply (red) |
| Insulated mounting |
TRUE |
| Material |
Plastic |
| Rated fault current |
0 A |
| Type of fastening |
Mounting with claw and screw |
| Imprint/indication |
None |
| RAL-number (similar) |
3020 |
| Impact strength |
IK07 |
| Transparent |
FALSE |
| Surface finishing |
Matt |
| With miniature fuse |
FALSE |
| With loop through function |
TRUE |
| Suitable for degree of protection (IP) |
IP20 |
| Device width |
180 mm |
| Device height |
50 mm |
| Device depth |
61 mm |
| Number of socket outlets switchable |
0 |
| With function lighting |
FALSE |
| With orientation lighting |
FALSE |
| Number of modules (module system) |
3 |
| IFTTT support available |
FALSE |
| Compatible with Apple HomeKit |
FALSE |
| Compatible with Google Assistant |
FALSE |
| Compatible with Amazon Alexa |
FALSE |
| Anti-bacterial treatment |
FALSE |
| UKCA |
da |
