Siemens 6GK7542-6VX00-0XE0 komunikacijski procesor za PLC-krmilnik

Blagovna znamka Siemens

(0 ocen)

1.229,00 EUR

Koda izdelka: 1745123
EAN: 4047622403563
Zaloga: 119 kosov na zalogi.
Predvidena dobava:17.05.2024 - 21.05.2024

Opis

Komunikacijski procesor CP 1542SP-1 IRC za povezavo SIMATIC S7-ET 200SP z Industrial Ethernet, SINAUT ST7, TeleControl Server Basic, IEC-60870-5-104 ali DNP3 protokolom v nadzorni center - Odprta komunikacija IE (TCP/IP, ISO -on -TCP, UDP), IP oddajanje/multicast, SNMPV1, DHCP, varna e-pošta, IPV4/IPV6, podpora za SINEMA Remote Connect s samodejno konfiguracijo časovne sinhronizacije preko NTP, dostop do spletnega strežnika CPU, adapter vodila zahtevano

Besedilo je strojno prevedeno.

Navodila za uporabo

Tehnični podatki 1745123 Siemens 6GK7542-6VX00-0XE0 komunikacijski procesor za PLC-krmilnik

Tehnični podatki

Vrsta zaščite	IP20
Vrsta	6GK7542-6VX00-0XE0
Min. temperatura okolice	0 °C
Maks. temperatura okolice	+60 °C
Proizv. št. delov	6GK75426VX000XE0
Način montaže (podrobnosti)	35 mm DIN montaža na tirnico
Mere	(D x Š) 74 mm x 60 mm
Dolžina	74 mm
Širina	60 mm
Width	60
Height	117 mm
Depth	74 mm
Suitable for safety functions	FALSE
Supporting protocol for LON	FALSE
Number of HW-interfaces industrial Ethernet	1
Number of HW-interfaces RS-232	0
Number of HW-interfaces RS-422	0
Number of HW-interfaces RS-485	0
Number of HW-interfaces serial TTY	0
Number of HW-interfaces USB	0
Number of HW-interfaces parallel	0
Number of HW-interfaces other	0
With optical interface	FALSE
Supporting protocol for TCP/IP	TRUE
Supporting protocol for ASI	FALSE
Supporting protocol for PROFIBUS	FALSE
Supporting protocol for CAN	FALSE
Supporting protocol for INTERBUS	FALSE
Supporting protocol for KNX	FALSE
Supporting protocol for Modbus	FALSE
Supporting protocol for Data-Highway	FALSE
Supporting protocol for DeviceNet	FALSE
Supporting protocol for SUCONET	FALSE
Supporting protocol for other bus systems	FALSE
Redundancy	FALSE
Transmission rate	100000000 kBit/s
With potential separation	FALSE
Explosion safety category for gas	None
Explosion safety category for dust	None
Appendant operation agent (Ex ia)	FALSE
Appendant operation agent (Ex ib)	FALSE
Supporting protocol for SERCOS	FALSE
Supporting protocol for INTERBUS-Safety	FALSE
Number of interfaces PROFINET	0
Number of HW-interfaces Wireless	0
Radio standard Bluetooth	FALSE
Radio standard Wi-Fi 802.11	FALSE
IO link master	FALSE
Performance level according to EN ISO 13849-1	None
Supporting protocol for AS-Interface Safety at Work	FALSE
Supporting protocol for DeviceNet Safety	FALSE
Supporting protocol for EtherNet/IP	FALSE
Supporting protocol for Foundation Fieldbus	FALSE
Supporting protocol for PROFINET CBA	FALSE
Supporting protocol for PROFINET IO	FALSE
Supporting protocol for PROFIsafe	FALSE
Supporting protocol for SafetyBUS p	FALSE
Type of data transmission	Other
SIL according to IEC 61508	None
Vrsta izdelka	komunikacijski procesor za PLC-krmilnik
